| Place of Origin: | Shenzhen, Guangdong, China |
|---|---|
| Brand Name: | SCANMAX |
| Certification: | CE,CF,RoHS |
| Model Number: | FT20 |
| Minimum Order Quantity: | 1 pcs |
| Price: | Negotiation |
| Packaging Details: | Normal craft paper and foam. |
| Delivery Time: | within 5 working days after receiving the balance |
| Payment Terms: | Western Union, T/T, paypal |
| Supply Ability: | 1000 PCS/ week |
| Operating Temperature: | ‐10℃ — +60°C | Operating System Requirements: | Android 7 Above |
|---|---|---|---|
| Focal Length: | 2.8mm | Full Resolution: | 30fps@1080P |
| Optical Size: | 1/2.5”inch COMS Sensor | Size: | 38mm X 38mm X 18±0.3mm |
| High Light: | desktop barcode reader,handheld uhf rfid reader |
||
Fever Screening Disinfection Features
*Small size, easy integrated,size :91mm (L)*48mm(W)*25mm(H);
*USB interface, easy to connect;
*Low power consumption;
*High image quality
*Accurate temperature measurement;
*Standard data interface, supporting secondary development, easy to integrate, and supporting access to various intelligent processing platforms.
Temperature Body Measuring Specification
| Specification | Value | |
| Optical Size | 1/2.5”inch COMS sensor | |
| Sensor Resolution | 2592 (H) x 1944 (V) | |
| Unit Pixel Size | 2.0*2.0um | |
| Color Filter | RGB Bayer pattem | |
| Shutter Type | Electronic Rolling Shutter | |
| Full Resolution | 30fps@1080P | |
| Visual Angle | 86° | |
| Aperture | 2.7 | |
| AEC/White Balance | Automatic | |
| Focus Distance | Fixation 50‐150cm | |
| Interface | USB 2.0 | |
| Power Supply DC | DC 5V ± 5% | |
| Size(Mm) | 38mm x 38mm x 18±0.3mm | |
| Operating Temperature | ‐10℃ — +60°C | |
| Operating System Requirements | Android 7 above | |
| Focal length | 2.8mm | |
|
Function consumption |
Standby | 30mA 士 5mA |
| Operating | 165mA 士 5mA @ 1920x1080 /30fps |
|
Attention
To protect you and others from injury or protect your device from damage, please read all the information below before using your device.
1. Make sure the camera doesn't look directly at high-intensity radiation sources such as the sun;
2. Do not touch the detector window with your hands or other objects;
3. Do not touch the device and cables with wet hands;
4. Do not bend or damage the connecting cables；
5. Do not scrub your equipment with thinner；
6. Do not plug or unplug other cables without disconnecting power；
7. Please do not connect the attached connecting cable incorrectly to avoid damage to the device；
8. Please pay attention to prevent static electricity；
9. Do not disassemble the device. If there is a malfunction, please contact our company and have it repaired by professionals
