RD006 RJ45 Wiegand 26/34 QR NFC Reader Access Control System

Basic Information
Place of Origin: China
Brand Name: Rakinda
Certification: CE,FCC,ROHS
Model Number: RD006
Image Sensor: 752X480 Light Source: White LED
Symbologies: PDF417, QR CODE, DATA MATRIX, Support Reading Screen And Printed Code Reading Distance: 10-55mm
Scan Angle: 360° Full Angle Power Input: 9-18VDC
Working Current: < 600mA Barcode Or 2D Code Input: Wiegand 26/ 34 Output, Output IC Card Number (common Read Head Function) And Associated Card Number Output In Compliance With QR Code Reservation Rules
Communication Interface: RJ45 10/100M TCP/IP, Extensible Wireless WIFI, Bluetooth
High Light:

600mA Access Control System


752X480 Access Control System


RD006 QR NFC Card Reader

QR Mifard Card TCP/IP Weigand 26/34 Reader Access Control System


Nowadays more and more Residential area, office area, factory using the access control device for managing the visitor visit. As it is more intelligent and more convenient. Our RD006 can read both Mifare card and QR code to get access. And Wifi and Bluetooth is optional. Its reading card region is very wide and can read card even in 20mm.

Rakinda Keep pace with times and research and development on access control system: RD006 that using in many places. The product has wiegand 26/34 output when the product is used as 1D 2D code reader, It's a kind of access control using 2D barcodes scanning based on TCP / IP based network.It can read QR code and mifare card both.


RD006 Selling Points:

1.QR+mifare card reader
2.TCP,IP weigand 26/34bit
3.Wifi , Bluetooth, POE optional
4. Free SDK ,API and engineer directly technical support.


What We Can Do?

Provide Free SDK,API ( Jave,C#,VC ...)
Provide Free Demo
Experienced Engineer Direct Help for Product Technical
OEM ODM Service Low MOQ



Product Parameters:

2D Code Engine Component Parameters
Image Sensor 752X480 CMOS
Light Source White LED
Symbologies 2D: PDF417, QR CODE, DATA MATRIX, Support reading screen and printed code
1D: CODE 128, UCC/EAN-128, AIM-128, EAN-8 etc.
Reading Distance 10-55mm
Scan Angle 360° Full Angle
Input and Output Parameters
Power Input 9-18VDC
Working Current < 600mA
Can read like ISO14443Aor ISO14443B card serial number Such as second-generation ID card, FM1208 CPU card, M1 card (Mifare S50, Mifare S70 IC card), SRIX4K, etc.
Barcode or 2D code input Wiegand 26/ 34 output, output IC card number (common read head function) and associated card number output in compliance with QR code reservation rules
Communication Interface RJ45 10/100M TCP/IP, Extensible Wireless WIFI, Bluetooth
Communication Protocol Support TCP / UDP / HTTP
Voice output comes with voice, amplifier and speaker output, nearly 150 kinds of voice output, customizable voice
Device input 12V DC power input, 1 line gate input, 1 line exit button input, 1 line alarm input
Equipment output 2 way 250V/5A relay output, 1 way unlock, 1 way expansion can control door opener, light, water valve, etc.
Wiegand output Wiegand 26/34 output
Installation size 152mm * 85mm * 35mm (L*W*H), Compatible with standard 86 boxRD006 RJ45 Wiegand 26/34 QR NFC Reader Access Control System 0RD006 RJ45 Wiegand 26/34 QR NFC Reader Access Control System 1RD006 RJ45 Wiegand 26/34 QR NFC Reader Access Control System 2RD006 RJ45 Wiegand 26/34 QR NFC Reader Access Control System 3RD006 RJ45 Wiegand 26/34 QR NFC Reader Access Control System 4RD006 RJ45 Wiegand 26/34 QR NFC Reader Access Control System 5RD006 RJ45 Wiegand 26/34 QR NFC Reader Access Control System 6

Company Profile:

Rakinda Technologies Co.,Ltd (The predecessor is Longview Tech Enterprise Co., Limited ) has been established since 2000, which has 6 branches in total, which are in Guangzhou, Shenzhen, Xiamen, Suzhou, Chengdu, Beijing and HongKong. "Rakinda" and "SCANMAX" are our two independent brands. Rakinda is also a leading worldwide Internet of Things solution provider, which is specialized in 1D/2D barcode identification technology (Embedded/Fixed Mount/Handheld/Desktop Barcode Scanner, Android PDA, Mobile POS, etc.) , radio frequency identification (UHF) technology and face recognition technology almost 20 years . We are oriented by customer demands , focus on development and innovation of intelligent systems and strive to provide most competitive IoT application solutions and services. Promoting people's lifestyle to be more intelligent is our infinite pursuit.



Q1: Can I get some samples? Are they free?
A1: We support 1pc sample order. Samples should be paid.
Q2: How can I buy?
A2: We are trade assurance supplier at Alibaba. You can start online order directly. Or pls contact us first according to the contact info. We will send you proper link directly.
Q3: What is your payment method?
A3: We accept Alibaba online orders, PayPal ,T /T, LC, Western Union , MoneyGram.
Q4: How long is your warranty time?
A4: Our officially promised warranty time is two years after delivery.
Q5: Where can we download the user manual of the scanners?
A5: We will send by email after you get samples.
Q6: What's the lead time?
A6: For sample, it is typically within 3 days. For bulk order, it depends on quantity and model you order.
Q7: Can you provide OEM service?
A7: Yes. We need further discuss about details.
