F7 Industrial-Grade Face Recognition Device with RGB and IR Camera

Basic Information
Place of Origin: China
Brand Name: Rakinda
Certification: CE FCC ROHS
Model Number: F7
Minimum Order Quantity: 1PCS
Packaging Details: 1pcs/box
Supply Ability: 10000+PCS+Month
System: Android 11.0 SC: Memory Of 2G, The Storage Of 16G
Touch Screen: Support Resolution Ratio: Two Million Pixels
Type: RGB And IR
High Light:

1000ml Hand Washing Disinfection Device

,

SS304Hand Washing Disinfection Device

,

3W Hand Sanitizer Dispenser

F7 is an advanced industrial-grade face recognition device with the following features and functions:
1. High-performance camera: It uses a 2-megapixel RGB+IR binocular camera to achieve high-quality image capture under various lighting conditions.
2. Liveness detection: It supports liveness detection through binocular camera technology, effectively preventing deception such as photos, videos or molds.
3. Face recognition algorithm: It has a built-in face recognition algorithm that can realize dynamic face recognition and complete identity authentication without the user's active cooperation.
4. Network connection: It supports WIFI and 10/100M Ethernet connection to ensure that the device can be flexibly deployed and integrated with other systems.
5. Security interface: It is equipped with a variety of peripheral security interfaces to meet various access control needs.
6. Multi-functional application: It can realize multiple functions such as personnel identity authentication, access management and attendance management.
7. Wide applicability: It is suitable for a variety of scenarios such as office buildings, office areas, hotels, schools, shopping malls, communities, public service facilities, stations and scenic exhibition halls.
8. Intelligent security control: It helps to realize intelligent security management of places and improve safety and efficiency.

This device combines advanced hardware and software technologies to provide users with a safe, efficient and easy-to-use face recognition solution, which is particularly suitable for places that require accurate identity verification and access management.



Parameters of Industrial-grade Facial Recognition

Face recognition machine

Product Features





Major Function Face recognition, access control
Service Environment Indoor and outdoor
Enclosure Aluminum alloy material, color

Camera

















Type RGB IR
Resolution Ratio Two million pixels Two million pixels
Iris Diaphragm F2.0±5% F2.0±5%
Focal Distance 4.3mm±5% 4.3mm±5%
Software Wide Dynamic voluntarily not have
Vertical Wide Angle 65° 65°
Horizontal Wide Angle 40° 40°
Infrared Light Supplement support
White Fill Light support

Core Parameters





System Android 11.0
CPU Quad-core 64-bit Cortex-A55 with the highest main frequency of 2.0GHz
SC Memory of 2G, the storage of 16G
Human-Computer Interaction Display Screen 6.95-inch, full view, 170 ° IPS LCD screen, 600 * 1024 resolution
Touch Screen Support
Human Sensing Module [Optional selection] Support
Human Body Temperature Measurement Module【Optional】 Test accuracy: 0.1℃
test error:≤±0.5℃
Temperature measurement distance: the recommended use distance is 50cm
Operating temperature: 15℃ ~40℃
Communication Mode Ethernet 10 / 100Mbps for Ethernet
WIFI Compliance to IEEE802.11b/g/n (2.4G)
4G [Optional selection] Support
RM Human Face support
Swing Card [Optional selection] Support
Brush Id Card [Optional selection] Support
Two-Dimension Code [Optional selection] Support

Joggle







Data Interface USB 2.0*1
Electric Relay Relay * 1
Gorge Line RS485 *1
Weigen 26bit / 34bit protocol
Source Adapter DC12V / 2A power supply

Environmental Requirements







Working Temperature -20℃~60℃
Working Humidity 20% to 90% (in the non condensing water droplet regime)
Static Electricity ESD IEC61000-4-2,LEVEL3
Levels Of Protection IP65 (This item is not supported in the temperature measurement version)
Way To Install Four Ways Wall-mounted plate, brake plate, landing version, desktop version



F7 Industrial-Grade Face Recognition Device with RGB and IR Camera 0F7 Industrial-Grade Face Recognition Device with RGB and IR Camera 1F7 Industrial-Grade Face Recognition Device with RGB and IR Camera 2F7 Industrial-Grade Face Recognition Device with RGB and IR Camera 3
