| Place of Origin: | CHINA |
|---|---|
| Brand Name: | RAKINDA |
| Certification: | CE/CCC/UN38.3/RoHS |
| Model Number: | S80 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Normal craft paper and foam |
| Delivery Time: | within 5 working days after receiving the balance |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 PCS/ week |
| Display: | 5.72inch 18:9 HD+(1440*720) | Size: | 162×76.8×13.9mm |
|---|---|---|---|
| Weight: | 252g(including Battery) | Network Connections: | 4G/3G/2G、Wi-Fi、GPRS |
| CPU: | Octa-core 2.0GHz | Protection Level: | IP67 |
| Certification: | CE/CCC/UN38.3/RoHS/IP67 | ||
| High Light: | desktop barcode reader,handheld uhf rfid reader |
||
Innovative technologysmooth and more efficient operation
* S80 is equipped with Octa core 2.0GHz CPU andAndroid11 OS with GMS certified,which issmooth,more secure and super experience
* With 4GB RAM+64GB ROM large memory,itworks smoother multitasking
* Highly integrated scanning.UHF RFID,NFC,PSAMin such small impact size
* A variety of scanning engine options to deal withall kinds of impossibilities
Light and large visionwith easy and free hand control
* 5.72 nch ful-view HD touch screen forsmooth vision and easy reading
* It can be used smoothly in wet hands,glovesand complex envrorments
* Light device bodly can be operated by one handcomfortable and convenient
Rebuilt classic 360°super protection strong and durable
* P67,1.5 m drap resstant,special desgned forharsh ervironments
* It is easy to deal with during bad weather suchas rain,snow and fog
Handheld Computer Parameters
| Basic Parameters | |
| Size | 162×76.8×13.9mm |
| Weight | 252g(including battery) |
| Display | 5.72inch 18:9 HD+(1440*720) |
| Touch panel | Gorilla glass,plated with anti-fingerprint film,supports wet hand operation |
| Backlit | LED Backlit |
| POWER | 4600mAh,3.8V removable lithium battery;spare batteryloptional):150mAh More than 8hours working time,and standby time 300hours |
| SIM | SIM+TF:nano sim+nano sim/TF Card |
| USB port | Type-c,Support OTG |
| Network connections | 4G/3G/2G,Wi-Fi,GPRS |
| Notification | Cue Tone;multi-colorled;Vibration |
| Keyboard | 3 virtual buttons:Back,Home,Menu |
| Audio frequency | Amicrophone,speaker,receiver |
| Performance Parameter | |
| CPU | Octa-core 2.0GHz |
| OS | Android 11 with GMS |
| Memory | Standard 4GB+64GB(LPDDR4X+EMMC), Option 3GB+32GB/6G+128G |
| Working environment | |
| Operating temperature | -20℃ to 55℃ |
| Humidity | 5%to 95%(Non-condensation) |
| Drop specification | Within the working temperature range,it can withstand repeated falls from a height of 1.5 meters to the concrete floor |
| Roll Specification | Can Withstand 200 times 1.6ft/0.5 m rolling impact;meets or exceeds IEC |
| Vibration | Random(10 Hz-30KHz);60 minutes per shaft |
| Electrostatic protection | +/-10kv air discharge +/-6kv contact discharge |
| Protection level | IP67 |
| Wireless Communication | |
| WWAN |
Asia+Europe band: GSM:Band 2/3/5/8 WCDMA:Band 1/2/5/8 TD-SCDMA:Band 34/39 CDMA:Band BC0 TDD-LTE:Band 34/38/39/40/41 FDD-LTE:Band 1/3/5/7/8/20 American band: GSM:Band 2/3/5/8 WCDMA:Band 1/2/4/5CDMA:Band BC0 TDD-LTE:Band 40/41 FDD-LTE:Band B1/2/4/5/7/28A/28B |
| WIFI |
Wifi Frequency:2.4GHz&5GHz Protocol:802.11a/b/g/n/ac/r/e/i Fast Roaming |
| navigation | Beidou,Glonass,GPS,Galileo,QZSS |
| Version | Bluetooth 5.0 |
| Data Collection | |
| Scanning engine | Professional scanner,one/two-dimensional barcode |
| Supported 1D barcode types |
UPC/EAN,Bookland EAN,UCC Coupon Code,ISSN EAN,Code 128,GS1-128,ISBT 128, Code 39,Trioptic Code 39,Code 32,Code 93, Code 11,Interleaved 2 of 5,Discrete 2 of 5,Codabar,MSl,Chinese 2 of 5,Korean 3 of 5,Matrix 2 of5,Inverse 1D,GS1 DataBar,Composite Codes |
| Supported 2D barcode types |
PDF417,MicroPDF417,Data Matrix,Data Matrix Inverse,Maxicode,QR Code,MicroQR,QR inverse,Aztec,Aztec Inverse,Postal Codes:US Postnet,US Planet,UK Postal,Australian Postal, Japan Postal,Netherlands KIX Code,USPS 4CB/One/Intelligent Mail,UPS FICS Pstal |
| Camera |
Front:5MP FF Rear:13MPAF,and2MP FF secondary camera(optional) |
| Internet of things function | |
| NFC |
working band:13.56MHz Support Protocol:MifareClassic (MF1)NDEF, Nfcv(15693),Ultraligh(MFO), IsoDep(CPU MF3),IsoDep(CPU)Read Distance:0-5cm |
| RFID |
Workingband:CHINA:920-925MHz; USA:902-928MHz;EU:865-868MHz; Protocol:ISO18000-6C/EPCC1G2 Read Distance:around 0.8m depends on thetags |
| Security PSAM | Supporting ISO7816 standard,supporting 1PSAM cards |
| Sensors | Light Sensor,distance sensor,gravity accelerometer,geomagnetic sensor,Hall Effect Sensor (Optional) |
| Others | |
| Certification | CE/CCC/UN38.3/RoHS/IP67 |
| Standard accessories | 5V/2A adapter/Data cable/battery/quick guide/UHF test tag |
| Optional accessories | Charging cradle/charging cradle adapter/battery/temperedglass /hand strap/pistol grip/lanyard |
