High Speed Handheld Pda Scanner , Wireless S1 Rugged Android Pda Reader

Basic Information
Place of Origin: China
Brand Name: Rakinda
Certification: CE CCC
Model Number: S1
Minimum Order Quantity: 1 PC
Price: negotiation
Packaging Details: packing in carton
Delivery Time: 1-3 work days
Supply Ability: 100 pcs per week
Size: 147.2x74.5x12mm Weight: 300g
Scan Speed:: 200 Scans/sec Interface: USB
Battery: 3600mAh Color: Orange
High Light:

barcode reader scanner


handheld uhf rfid reader

Rakinda China wireless handheld S1 rugged ip65 android pda/ reader handheld pda



Physical Characteristics
Dimension 147.2x74.5x12mm
Weight 300g
screen 5"HD(1280X720)screen
Audio speaker, 2 microphones
Interfaces micro USB support OTG
CPU Quad core 1.2GHz,dominant frequency
Expansion Supports up to 32 GB Micro SD card
Developing Environment
Operating System Android 5.1
SDK Rakinda Software Development Kit
Language Java
Tool Eclipse / Android Studio
User Environment
Operating Temperature -25°C to 60°C
Storage Temperature -40°C to 70°C
Humidity 5% - 95%RH (Non-condensing)
Sealing IP65
Drop Specification Multiple 1.5m (at least 20 times) to the concrete across the operating temperature range
WLAN WiFi 802.11a/b/g/n(Dual-band 2.4GHz/5GHz)
Bluetooth support bluetooth 3.0
GNSS GPS/AGPS, GLONASS, BeiDou; internal antenna
Frequency 13.56MHz
Protocol ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc
Chips M1 card (S50, S70), CPU card, NFC tags, etc.
Range 2-4cm
Camera 13MP autofocus camera with flash
Barcode Scanners (Optional)
2D Imager Scanner Zebra SE4710/Honeywell N6603
1D Symbologies UPC/EAN, Code128, Code39, Code93, Code11, Codabar, Interleaved 2 of5, Discrete 2 of 5, Chinese 2 of 5, MSI, RSS, etc
2D Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, DutchPostal (KIX), etc



High Speed Handheld Pda Scanner , Wireless S1 Rugged Android Pda Reader 0



1, express logistics. Typical courier, postal delivery, e-commerce delivery, tobacco distribution, warehouse inventory, as well as the terminal distribution of major manufacturers of daily necessities, pharmaceutical distribution, factory logistics in large factories, logistics warehouse to warehouse transport. According to different systems, the logistics system uses different handheld PDA expansion functions. The main functions are barcode scanning, contact / contactless IC card reading and writing and WiFi, Bluetooth data communication and so on.


2, three meter reading. In the foreseeable future, this is a relatively large capacity market. Three tables meter handheld PDA devices integrated into the expansion of the main functions of power infrared, bar code scanning and data communications and so on.


3 Retail. When more and more supermarkets and counter space have been unable to meet the rapid transaction time, handheld PDA-based mobile applications can be used for timely and accurate single product replenishment, receiving and dispatching, shelving, inventory, price verification, mobile Price management, mobile shopping guide to achieve quick cashier, divert the peak Passenger.
