| Place of Origin: | Shenzhen, Guangdong, China |
|---|---|
| Brand Name: | RAKINDA |
| Certification: | CE, RoHS |
| Model Number: | LV4500 |
| Minimum Order Quantity: | 1 pcs |
| Price: | Negotiation |
| Packaging Details: | barcode scanner+USB/RS232 Cable+ Power Adaptor(for RS232 only). Normal craft paper and foam. |
| Delivery Time: | within 5 working days after receiving the balance |
| Payment Terms: | Western Union, T/T, paypal |
| Supply Ability: | 1000 PCS/ week |
| Features: | Big Scanning Window With White Light | Item Name: | Fixed Mount 2D Barcode Scanner |
|---|---|---|---|
| Reading Precision: | ≥ 10mil | Cable: | USB, RS232 |
| Color: | All Black | Operating Voltage: | 3.3±10% VDC |
| Weight: | 280g | Size: | 78.6 X 67.3 X 55.3mm |
| Highlight: | fixed mount barcode reader,arduino barcode reader |
||
LV4500 2D Fixed Mount Barcode Scanner With long and short range distance
At present, NFC applications have a bright future. All parties including Internet companies, CUP, banks, mobile operators and handset manufacturers are stepping up their efforts in construction. With the smart phone upgrade, NFC has slowly become the standard. In many ways, it is undeniable that NFC payment products dominated by Unionpay have obvious security advantages over 2d code payment, and versatility has also rapidly risen with the upgrade of terminal manufacturers. NFC will enter the main stage of mobile payment. If the 2d code leads to new technical solutions in security, the mobile payment market may turn into NFC and 2d code.
Shenzhen Rakinda LV4500 which is good for reading both phone screen and printer and it can be long range and short range distance as customer requirement , it is absolutely good for reading QR code , the best choice for customer
Technical Specifications of LV4500 Fixed Mount 2D Barcode Scanner
| Performance | Image Sensor | 752*480 CMOS | ||
| Illumination | White LED | |||
| Symbologies | 2D | PDF417, Data Matrix, QR Code, Chinese Sensible Code. | ||
| 1D | EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128 (FNC1, FNC2, FNC3), Code 93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar (RSS-Expand, RSS-Limited, RSS-14), Code 39, Code 11, MSI-Plessey, Plessey. | |||
| Resolution* | ≥ 5 mil | |||
| Scan Mode | Sense mode, Continuous mode | |||
| Scan Angle** | Pitch: ±40°, Roll: 360°, Skew: ±40° | |||
| Scan Window | 31.5mm×46.5mm | |||
| Symbol Contrast | ≥25% | |||
| Interface | RS-232, USB | |||
| FOV | Horizontal: 75°, Vertical: 50° | |||
| Physical/Electric | Dimensions (LxWxH) | 78.7(W)×67.7(D)×53(H)mm (max.) | ||
| Weight | 173 g | |||
| Notification | Beep | |||
| Power consumption | 534mW (typical) | |||
| Operating Voltage | 5VDC±5% | |||
| Current@5VDC | Operating Current: 108mA (typical), 114mA (max.) | |||
| Environmental | Operating Temperature | -20℃~60℃ | ||
| Storage Temperature | -40℃~70℃ | |||
| Humidity | 5%~95% (non-condensing) | |||
| ESD | ±8 KV (air discharge); ±4 KV (direct discharge) | |||
| Certification | FCC Part15 Class B, CE EMC Class B | |||
| Accessories | Cable | USB | Used to connect the scanner to a host device. | |
| RS-232 | Used to connect the scanner to a host device. | |||
