| Place of Origin: | China |
|---|---|
| Brand Name: | Rakinda |
| Certification: | CE FCC RoHS |
| Model Number: | RD006 |
| Minimum Order Quantity: | 1pc |
| Packaging Details: | carton package |
| Delivery Time: | 1-5 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1000 pcs per month |
| Reading Distance: | 10-55mm | Barcode/Card: | 1D/2D Barcode, IC Card |
|---|---|---|---|
| Wiegand: | Wiegand 26/34 | Relay: | 2 |
| Network: | RJ45 10 / 100M TCP / IP | Power Input: | 9-18VDC |
| High Light: | RFID Qr Code Reader,RFID Wiegand Barcode Scanner,Qr Code Reader Wiegand Barcode Scanner |
||
RFID Qr Code Reader Wiegand Barcode Scanner 2 Replay Output
2 Relay Wiegand Door Access Control QR Code Scanner RFID Reader
RD006 Access Control Barcode Scanner Description:
The product has Wiegand 26/ 34 output, when the product is used as a 2d code reader, which can make the traditional access control, ladder control, yard products, own the 2d code access function immediately without changing the main controller.Besides, RD006 has 2-channel relay output, in addition to 1 channel to control the door lock, other 1 channel to control the door opener, lights, players, valves and so on. Support
TCP/IP remote IAP upgrade. If there is a change in requirements, after modifying the program, it can be completed directly through the network upgrade.
RD006 QR Access Control Device Features:
1. Barcode/QR Code reading is standard function, IC/Mifare card reading is optional.
2. It can read both printed or mobile screen barcodes.
3. Free sdk and demo software.
4. Customizable audio.
5. With built-in access controller, and 2 replay output.
6. Wifi, Bluetooth or POE function can be added.
RD006 and RD008 Parameters:
| Model Name | RD006 | RD008 |
| Processor | ARM+DSP core | ARM+DSP core |
| Memory | 85,000 people, 100,000 events | 85,000 people, 100,000 events |
| Verification Speed | QR code recognition <0.5S, card recognition <0.1S | QR code recognition <0.5S, card recognition <0.1S |
| Communication Method | TCP/IP access, expandable WIFI, bluetooth can be compatible | TCP/IP access, expandable WIFI, bluetooth can be compatible |
| Run Offline | Support offline operation | Support offline operation |
| Input and Output Ports | Control lock output, exit button and door sensor input, etc. | Control lock output, exit button and door sensor input, etc. |
| Security | Input overcurrent protection, instantaneous overvoltage protection | Input overcurrent protection, instantaneous overvoltage protection |
| Power/power Consumption | Voltage 12VDC, current <1A | Voltage 12VDC, current <1A |
| Working Environment | Humidity 5%~95%, temperature -20℃~60℃ | Humidity 5%~95%, temperature -20℃~60℃ |
| Weight | 300g | 400g |
| Size | 105*105*25mm | 110*25*34.62mm |
| Relay | 2 relay | 1 relay |
| Material and Display | aluminum alloy Plastic with TFT display | RD008 has 1.8-inch TFT color screen, aluminum alloy round case |
| Standard | RJ45 TCP IP Wiegand output | RJ45 TCP IP(Weigand Optional ) |
| Optional | BT Wifi POE | BT Wifi |
Independent R&D Center
Our Independent R&D Center keeps focusing on IoT design and manufacture, we have rich theoretical knowledge, practical experience, professional design and products manufacture ability, so as to meet all kinds of customers requirements. Through joint efforts of our team, we have been granted National High-tech Enterprise Award ,Software Product certificate and Software Enterprise certificate. At present, Rakinda has provided complete and mature solutions and technical support in these fields of access control, kiosk, turnstile, vending machine, smart retail, smart hotel, smart campus and smart medical treatment. So far we have won unanimous praise of the industry.
Service Advantages
1. Professional service team, all-round one-to-one person follow-up.
2. Provide professional development kits to help customers solve various related software and hardware developing issues.
3. Two-year quality assurance, life-long maintenance and 24-hour service hotline guarantee the customers' interest.
We create a bright future with hand in hand and implement the business philosophy of customer first. Through continuous exploration and innovation, we aim to achieve win-win cooperation with customers in near future together!
