TCP HTTP QR Code Reader Access Control Wiegand IC Card Reader RS232

Basic Information
Place of Origin: Shenzhen, Guangdong, China
Brand Name: RAKINDA
Certification: CE ROHS FCC
Model Number: RD800
Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: Normal craft paper and foam.
Delivery Time: within 5 working days after receiving the balance
Payment Terms: Credit card, T/T, paypal
Supply Ability: 2000 PCS/ month
PCB Size: 160mm × 150 Mm Operating Temperature:: -20℃ — 65℃
Communication Port:: TCP/IP Network Port RS232 Serial Port:: 2 Channels, Connect QR Code Scanner/ID Card Reader
Reader Port:: 2 Channels, Support Wiegand 26/34 Reader Relay Output:: Omron Relay DC30V/5A, 250VAC/5A
High Light:

TCP QR Code Reader Access Control


ODM QR Code Reader Access Control


ODM qr code door access control

TCP HTTP QR Code Reader Access Control Wiegand IC Card Reader RS232


TCP/HTTP Ethernet Port QR Reader Access Controller Wiegand IC card reader RS232 for turnstile


RD800 QR code Access Controller description:


QR code access controller is a two-dimensional code network access controller developed based on 32-bit embedded
ARM high-performance processor and multi-task embedded real-time operating system, combined with two-dimensional code
scanning head and electronic control door lock, Door sensor and other equipment form a stable, reliable, intelligent and safe
QR code access control management system. It is widely used in the access control management of banks, prisons, police stations,
office buildings, residential districts, large state-owned enterprises and enterprises and institutions.
Free SDK can be provided for your integration with you access control system.

Application scenario: Gym, Elevator, Building office, turnstile access control.


RD800 TCP/Http access controller main features:


Key performance characteristics:
1: The controller is based on a 32-bit ARM microprocessor platform;
2: Built-in multi-task embedded real-time operating system in the controller;
3: Using DataFlash and ferroelectric memory, the data will not be lost for 10 years after power failure;
4: The controller card capacity is 65,000 pieces, and the event capacity is 100,000 pieces, which can be
    expanded; the capacity of QR code is 100,000 times
5: Support TCP/IP communication mode, support WAN connection;
6: Support connection of different types of identification devices: QR code scanner, ID/IC card reader,
     password reader, biometric card reader, etc.;
7: Support multiple door opening methods such as scanning the QR code to open the door, swiping the card
     to open the door, card + password to open the door, super password to open the door, dual card toopen the door,
     first card to open the door, duress code to open the door, emergency full open and full closed, forced door
     normally open and normally closed;
8: It can realize the independent and complete control of 1 access door: including the control of in and
     out bidirectional card reader and QR code scanning head;
9:  It can realize the control of the time period for all personnel to enter and exit;
10: Support remote download and remote upgrade;


TCP HTTP QR Code Reader Access Control Wiegand IC Card Reader RS232 0

TCP HTTP QR Code Reader Access Control Wiegand IC Card Reader RS232 1

TCP HTTP QR Code Reader Access Control Wiegand IC Card Reader RS232 2

TCP HTTP QR Code Reader Access Control Wiegand IC Card Reader RS232 3

TCP HTTP QR Code Reader Access Control Wiegand IC Card Reader RS232 4


Company Advantages:

Our company is specialized in barcode scanner for 20 years since 2000, we have professional research

developement team, has our own factory, support OEM design. We have many customers from different

countries already. And we are Gold supplier in the Alibaba. Our product is certificated by CE,ROHS and FCC.



Q1: Can I get some samples? Are they free?
A1: We support 1-2pcs sample order. Samples should be paid.


Q2: How can I buy?
A2: We are trade assurance supplier at Alibaba. You can start online order directly. Or pls contact us directly

according to the contact info. We will send you proper link directly.


Q3: What is your payment method?
A3: We accept Alibaba online orders by Credit card, PayPal ,T /T


Q4: How long is your warranty time?
A4: Our officially promised warranty time is 1 year after delivery.


Q5: Where can we download the user manual of the scanners?
A5: We will send by email after you get samples.


Q6: What's the lead time?
A6: For sample, it is typically within 5-7days by DHL. For bulk order, it depends on quantity and model you order.


Q7: Can you provide OEM service?
A7: Yes. We need further discuss about details.


Q8: If I come across any problem during product using, where I can get the support ?
A8: We support you technically 24h/7.please send all your questions to us. and we will give the professional,patient,

expliantion by email or call in time.


Q9: How do you ship the scanners usually?
A9: Since it is light and compact, we usually use DHL, UPS, Fedex, TNT and post air mail. We also can ship the goods by your shipping account or other express agent you provided.
