| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | Rakinda |
| Certification: | CE FCC ROHS |
| Model Number: | LV1400 |
| Minimum Order Quantity: | 1 piece |
| Price: | 45 USD/PCS |
| Packaging Details: | package in carton; |
| Delivery Time: | 3-5 working days |
| Payment Terms: | Western Union, T/T, paypal |
| Supply Ability: | 1000 piece for a week |
| Name: | Barcode Scanner Module | Light Source: | Visible 632nm Red Light |
|---|---|---|---|
| Processor: | ARM32-bit | Interface: | KB |
| Weight: | 6g | Brand: | Rakinda |
| High Light: | CCD 2d Barcode Module,ARM32 2d Barcode Module,ARM32 barcode reader module |
||
LV1400 is a sort of embedded 1D CCD barcode scanner module.This module uses the domestic leading CCD imaging technology with USB,TTL-RS232, PS2 interface, support manual 1D codes. The module is special for OEM application with 32CPU processor can up to 300scans.Compact size can easily be embedded to all kinds of equipment, integration component to increase the stability and reliability.
Characteristic
1. Linear barcode scanning: Fast and easy to scan print code, paper code, screen code. It even has great performance for damaged, clumped, stain codes have great performance.
2. Compact design: With less than 12MM height, the module can be easily embedded to equipment .
3.Multiple interfaces: Manual USB port, TTL-RS232, PS2, support POS machine and Android system.
4. Integration: High quality CPU ensures fast and accurate scans
LV1400 Datasheet.pdf
| Device Weight | <6g |
| Device Dimension | 26.5mm L* 20mm W * 11.5mm H |
| Cable Length | 1500mm(optional) |
| Interface | KB (PS/2 ) |
| Connector | FFC 12pin pitch 0.5 |
| Performance parameters | |
| Light source | visible 632nm red light |
| Image Sensor | Linear CCD Sensor |
| Processor | ARM32-bit |
| Depth of field | 3-50CM |
| Resolution | ≥3mil/0.1mm@PCS90% |
| Print Contrast | 25%PCS |
| Work Voltage | DC 3.3-5V |
| Electriccurrent | 110mA(work)；30mA(stand by) |
| Image Resolution | 2500dpi |
| Ambient illumination | 100,000Lux Max |
| EAN-8, EAN-13, Codabar, CODE 11, CODE 39, CODE 93, CODE128,China | |
| Post, GS1-128, GS1 Limited, GS1 Omnidirectional, UPC-A, UPC-E, | |
| Decode Capability | ISBN/ISSN, ISBT , Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, MSI, |
| Plessey, ITF14. | |
| Environmental parameters | |
| Operating Temperature | -20℃ to 50℃ |
| Storage Temperature | -40℃ to 70℃ |
| Relative humidity | 5% to 95%(Non-condensing) |
| Drop test | 1.2meter,100times |
| Shock resistance | 10H@125RPM |
