| Place of Origin: | China |
|---|---|
| Brand Name: | Rakinda |
| Certification: | CE, FCC, ROHS |
| Model Number: | LV3000U Plus |
| Minimum Order Quantity: | 2pcs |
| Price: | USD 199/pc |
| Packaging Details: | cartoon package |
| Delivery Time: | 3-5 days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 3000pcs per month |
| IP: | 68 | Feature: | Industrial Conveyor |
|---|---|---|---|
| Interface: | RS232 | Scanning Moving Code: | Support |
| Customized: | Support | I/O Controller: | Available |
| Resolution: | 1280*800 CMOS | ||
| Highlight: | IP68 Barcode Reader Module,MRZ Code Reader,Datamatrix Barcode Reader Module |
||
IP68 Barcode Reader Module Datamatrix AZTEC MRZ Code Reader RS232
Outdoor Conveyor QR code scanner IP68 waterproof datamatrix AZTEC MRZ code reader RS232
1. Product Description
LV3000U Plus using Rakinda latest algorithem and technology, it can scan the code easily and fastly. With specially designed enclosure, it is waterproof and dustproof industrial level, which can be used for conveyor and production line in scanning moving barcode.
LV3000U Plus is a perfect fixed mount barcode scanner for low and middle speed production line application due to its high performance and cost ratio.
Rakinda has own hardware and software team. We can provide customized software solution together with the fixed barcode scanner. Barcode Scanner system is an important part in industrial 4.0 unmanned production line, which can improve the efficiency, reduce error rate and also reduce labor cost.
2. LV3000U Plus Fixed Mount Barcode Scanner Feature
2.1 Scan fast moving code on conveyor;
2.2 IP68 waterproof dustproof enclosure, which is industrial level;
2.3 RS232 cable for stable data communication
3. LV3000U Plus Fixed Barcode Scanner Specifications
| Performance | Image Sensor | 1280*800 CMOS | |
| Illumination | White LED | ||
| Aiming | Laser Crosshair LED | ||
| Symbologies | 2D | PDF417, Data Matrix, QR code, Chinese Sensible Code, AZTEC | |
| 1D | Code128, EAN-13, EAN-8, Code39,UPC-A, Interleaved 2 of 5 | ||
| Resolution | ≥3mil | ||
| Mechanical/Electrical | Interface | RS-232 | |
| Rated Power Consumption | 1622mW (typical) | ||
| Operating Voltage | 5VDC±5% | ||
| Dimensions | 45.5(W)*55.5(D)*28.5(H)mm | ||
| Weight | 75g |
4. LV3000U Plus Fixed Scanner Application:
The scanner has wide and typical application in production line, conveyor, kiosk, turnstile etc.
5. LV3000U Plus Fixed Barcode Scanner Advantages:
5.1 Capable of scanning moving code;
5.2 High greade industrial enclosure
5.3 Accept OEM and customized requirement
5.4 Two yeas warranty
