| Place of Origin: | Shenzhen, Guangdong, China |
|---|---|
| Brand Name: | RAKINDA |
| Certification: | CE,CF,RoHS |
| Model Number: | RD6100 |
| Minimum Order Quantity: | 1 pcs |
| Price: | Negotiation |
| Packaging Details: | Normal craft paper and foam |
| Delivery Time: | Within 5 working days after receiving the balance |
| Payment Terms: | Western Union, T/T, Paypal |
| Supply Ability: | 1000 PCS/ week |
| Image Sensor: | 1280 * 1088 CMOS | Interface: | RS-232, USB, RS-485, Wiegand |
|---|---|---|---|
| Operating Voltage: | 5-24VDC±5% | Weight: | 132g |
| Notification: | Beeper, Multi-colored LED Indicator | Sealing: | IP67 (not Including Interface) |
| Highlight: | 1000ML Hand Disinfectant Dispenser,10CM Hand Disinfectant Dispenser,1000ML hand sanitizer machine |
||
The RD6100 is a robust, high-performance fixed mount barcode scanner engineered for demanding industrial automation and logistics sorting applications. Built with a superior 1D/2D imaging engine, it effortlessly decodes printed and on-screen barcodes, even those that are damaged or poorly printed. Its IP67 rating ensures reliable operation in dusty or wet environments, making it the ideal fixed position scanner for conveyor belts, parcel lockers, and automated handling systems. With wide voltage input (5-24VDC) and support for multiple interfaces like RS-485 and Wiegand, the RD6100 integrates seamlessly into any industrial setup.
Key Features:
**Superior 1D/2D Barcode Reading: Decodes all major symbologies, including QR Code, Data Matrix, and Code 128 with exceptional speed and accuracy.
**Rugged IP67 Construction: Dustproof and waterproof design for reliable performance in harsh industrial environments.
**Versatile Integration: Supports RS-232, USB, and optional RS-485 & Wiegand interfaces for flexible connectivity.
**Wide Voltage Input: Operates on 5-24VDC, simplifying power supply requirements in industrial settings.
Parameters of Self-service Kiosk Barcode Scanner
| Performance | ||
| Image Sensor | 1280 * 1088 CMOS | Illumination 3000K white LED |
| Symbologies | 2D | PDF417, Data Matrix, QR Code, Micro QR, Aztec, etc. |
| 1D | EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Interleaved 2 of 5, Code 128 (FNC1), Code 93, ITF-6, ITF-14, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, Code 11, GS1 Databar (RSS-Expand, RSS-Limited, RSS-14), MSI Plessey, Code 39 (Code 39 FULL ASCII), Plessey, etc | |
| Postal | USPS Postnet, USPS Intelligent Mail, Royal Mail, USPS Planet, KIX Post, Australian Postal, Japan Post | |
| OCR | Passport OCR, Chinese ID Card, China Travel Permit OCR | |
| Physical | ||
| Interface | RS-232, USB, RS-485, Wiegand | |
| NFC (optional) 3 | Reading Distance Supported | 0-30mm |
| Functions | Support reading card number and card type, reading and writing sectors, increasing and decreasing values, reading and writing files, file operations, key operations, contactless CPU card operation (ISO14443 Type A) and APDU. | |
| Supported Cards | ID card, NFC-equipped phone, Mifare Classic, Mifare Plus, Mifare Ultralight/C/EV1, Mifare Desfire, CPU card, NTAG2x series, NTAG42x series, ICODE 2, Type B card ,Felica card | |
| Operating Voltage | 5-24VDC±5% | |
| Current@5VDC | NFC Version | Non-NFC Version |
| Operating (RMS) 4 Idle | 220mA | 172mA |
| 175mA | 118mA | |
| Dimensions | ||
| Weight | 132g | |
| Notification | Beeper, multi-colored LED indicator | |
| Environmental | ||
| Operating Temperature Storage Temperature | -20℃ to 60℃ (-4°F to 140°F) | |
| Humidity | -40℃ to 85℃ (-40°F to 185°F) 5%~95% (non-condensing) | |
| ESD | ±15kV (air discharge) ±8kV (direct discharge) | |
| Sealing | IP67 (not including interface) | |
| Accessories | ||
| Cable | Optional | |
| Optional | ||
| Optional | ||
| Optional | ||
| Power Adapter | USB cable used to connect the scanner to a host device. | |
| RS-232 cable used to connect the scanner to a host device. | ||
|
RS-485 and Wiegand cables used to connect the scanner to a host device. DC5V power adapter to provide power for the scanner with RS-232 cable. |
||
