Powerful 1D 2D Handheld Barcode Scanner Bluetooth Tiny Shape USB Micro Host Interface

Basic Information
Place of Origin: China
Brand Name: Rakinda
Certification: CE, FCC, ROHS
Model Number: RD5
Minimum Order Quantity: 1pc
Packaging Details: carton package
Delivery Time: 1-7 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000pcs per month
Size: 100*40*17mm Host Interface: USB Micro
Packaging Weight: 569g Scanner Weight: 70g
Operating Time: At Least 10 Hours (continuous Scanning) Battery Capacity: 1200mAH
High Light:

desktop barcode reader


handheld barcode reader

Product Description:

1. The RD5 Bluetooth barcode scanner is the way to go for mobile scanning. Tiny but powerful, the RD5 features simple pairing to any smartphone, tablet, or computer.
2. The RD5 was designed for integration into field sales / service, retail, and supply chains. However, this barcode scanner is a versatile tool for anyone on the go.
3. This compact barcode scanner facilitates a variety of field-based applications: streamlining merchandising, order fulfillment, and route accounting.
4. Food and beverage centers, pharmaceuticals, logistics centers, and those working in general distribution can benefit significantly from this barcode scanner's expanded capabilities.
5. Use the RD5 for gift registry and inventory in retail or proof-of-delivery for courier services.


RD5 Datasheet.pdf


1. Build in high performance 1D/2D engine & decoder to read all standard 1D, 2D and PDF417,Qr codes.
2. Bluetooth wireless transmission distance up to 50M.
3. User-friendly operation with a pocket-sized enclosure.
4. Design for reading barcodes displayed on the LCD screens of mobile devices.
5. Compatible with Windows, Android, and IOS mobile devices by HID and SPP connection.
6. Enterprise durability: 1.5 m drop protection and IP42 sealing for ingress protection.
7. Built in 32MB memory, offline continuous operation, with storage, inventory function.



Host interface USB Micro
Transmission distance 50 meters (within visual range)
Wireless specifications Bluetooth V4.0
Battery Specification rechargeable lithium battery (replaceable)
Battery capacity 1200mAH
Charging time 3.5 hours
Operating time at least 10 hours (continuous scanning)
Standby time 100 days
Parameter Optical & Performance
Scan type

1D: 1D Laser or CCD Module;

2D: CMOS sensor with 640 x 480 pixel

Light Source

1D: 650 nm visible laser diob or Visible LED 625 nm;

2D: White LED with CCT 5000K

Max. Resolution

1D: 4mil(laser) or 5mil(ccd);

2D: 0–100,000 lux (total darkness to bright sunlight)


1D Code, 1D Postal Code

2D Code, 2D Postal Code

Operation Mode

1D: UPC-A, UPC-E, EAN-8, EAN-13, CODE 39, CODE 128, GS1 128, I 2 of 5, NEC 2 of 5, CODE 93, Codabar, GS1DataBar Omn, GS1DataBar Ltd, GS1DataBar Exp, CODE 11, MSI, UPC-E1, S 2 of 5 Indus, S 2 of 5 IATA, Matrix 2 of 5, China Post, Korea Post.

2D: QR Code, Data Matrix, Aztec Code, PDF417, Macro PDF417, Micro PDF417, MaxiCode, Codablock A, Codablock F, GS1

Machine specifications
Scanner size 100*40*17mm
Scanner weight 70g
Environmental(IP Rating IP42)
Operating Temperature 0°C to 50°C
Storage Temperature -30°C to 70°C
Regulatory Approvals CE, FCC, ROHS
Accessories Lanyard, Micro USB cable, Bluetooth receiver
Packaging Dimension 200mm*130mm*130mm(L*W*H)
Packaging Weight
