| Place of Origin: | China |
|---|---|
| Brand Name: | Rakinda |
| Certification: | CE FCC ROHS |
| Model Number: | RD006 |
| Minimum Order Quantity: | 1 PC |
| Price: | negotiation |
| Packaging Details: | packing in carton |
| Delivery Time: | 1-3 work days |
| Supply Ability: | 100 pcs per week |
| Unlocking Method: | QR Code, IC Card | Power Supply: | 9-18V DC (Optional: POE) |
|---|---|---|---|
| Reading Distance: | 10-55mm | Relay: | 2 Relay |
| Wiegand: | Wiegand 26/34 | OEM: | Logo, Voice Customizable |
| Highlight: | Digital Qr Code Access Control Reader,Qr Code Mifare Card Reader,Mifare Qr Code Access Control Reader |
||
Digital Qr Code Access Control Reader Mifare Card Reader Wiegand 26
Digital QR Code Scanner Mifare Card Reader Wall Mounted Door Lock
RD006 Digital QR Code Scanner Features
1. Embedded multitasking real-time operating system, system can be fully activated with 3 seconds.
2. Single-door access control + 2d code scanner engine + the second generation ID card reader three in one card products. Make site installation and maintenance become simple with lower cost.
3. The product has Wiegand 26/ 34 output, when the product is used as a 2d code reader, which can make the traditional access control, ladder control, yard products, own the 2d code access function immediately without changing the main controller. And can access legally when it must comply with the rules of the 2d code so that the traditional access control, ladder control and yard products have a real CPU system security level at once and reduce system costs greatly.
4. The product has 2-channel relay output, in addition to 1 channel to control the
door lock, other 1 channel to control the door opener, lights, players, valves and so on.
5.The product has voice amplifier and speakers whose commonly used access incidents can be set, the network control play nearly 150 voices that can be customized.
Input and Output Parameters:
1. Power Input: 9-18VDC
2. Working Current: < 600mA
3. Support ISO14443Aor ISO14443B card
4. Barcode or 2D code input.
5. Wiegand 26/ 34 output
6. Communication Interface: RJ45 10/100M TCP/IP, Extensible Wireless WIFI,Bluetooth
7. Communication Protocol: Support TCP / UDP / HTTP
8. Device input: 12V DC power input, 1 line gate input, 1 line exit button input, 1 line alarm input
10. Equipment output: 2 way 250V/5A relay output, 1 way unlock, 1 way expansion can control door opener, light, water valve, etc.
RD006/RD008 Parameters:
Product Parameters:
| Model Name | RD006 | RD008 |
| Processor | ARM+DSP core | ARM+DSP core |
| Memory | 85,000 people, 100,000 events | 85,000 people, 100,000 events |
| Verification Speed | QR code recognition <0.5S, card recognition <0.1S | QR code recognition <0.5S, card recognition <0.1S |
| Communication Method | TCP/IP access, expandable WIFI, bluetooth can be compatible | TCP/IP access, expandable WIFI, bluetooth can be compatible |
| Run Offline | Support offline operation | Support offline operation |
| Input and Output Ports | Control lock output, exit button and door sensor input, etc. | Control lock output, exit button and door sensor input, etc. |
| Security | Input overcurrent protection, instantaneous overvoltage protection | Input overcurrent protection, instantaneous overvoltage protection |
| Power/power Consumption | Voltage 12VDC, current <1A | Voltage 12VDC, current <1A |
| Working Environment | Humidity 5%~95%, temperature -20℃~60℃ | Humidity 5%~95%, temperature -20℃~60℃ |
| Weight | 300g | 400g |
| Size | 105*105*25mm | 110*25*34.62mm |
| Relay | 2 relay | 1 relay |
| Material and Display | aluminum alloy Plastic with TFT display | RD008 has 1.8-inch TFT color screen, aluminum alloy round case |
| Standard | RJ45 TCP IP Wiegand output | RJ45 TCP IP(Weigand Optional ) |
| Optional | BT Wifi POE | BT Wifi |
Q1: Can I get some samples? Are they free?
A1: We support 1pc sample order. Samples should be paid.
Q2: How can I buy?
A2: We are trade assurance supplier at Alibaba. You can start online order directly. Or pls contact us first according to the contact info. We will send you proper link directly.
Q3: What is your payment method?
A3: We accept Alibaba online orders, PayPal ,T /T, LC, Western Union , MoneyGram.
Q4: How long is your warranty time?
A4: Our officially promised warranty time is two years after delivery.
Q5: Where can we download the user manual of the scanners?
A5: We will send by email after you get samples.
Q6: What's the lead time?
A6: For sample, it is typically within 3 days. For bulk order, it depends on quantity and model you order.
