| Place of Origin: | China |
|---|---|
| Brand Name: | Rakinda |
| Certification: | CE FCC ROHS |
| Model Number: | S2-2 |
| Minimum Order Quantity: | 1pcs |
| Packaging Details: | 1pcs/box |
| Supply Ability: | 100pcs per week |
| Resolution: | 1280 Pixels(H) X 1024 Pixels(V) | Reading Accuracy: | 1D : ≥3 Mil ; 2D : ≥5 Mil |
|---|---|---|---|
| Field Of View: | Level 41° (H)，Plumb 35° (V); | Weight: | 150g |
| Storage Temperature: | -40℃~+70℃ | ||
| Highlight: | SS304 Face Recognition Temperature Measurement,SS201 Face Recognition Temperature Measurement,SS304 face recognition thermometer terminal |
||
A handheld industrial Direct Part Marking (DPM) barcode scanner is a specialized device designed to read and decode barcodes that are marked directly on an item. DPM barcodes are often used in industrial settings where traditional paper or label-based barcodes may not be suitable due to factors like durability requirements, harsh environments, or small item sizes.
There are two series of 1.3 million pixels:
S2-1: High-performance barcode reading equipment with 130-pixel global shutter, specially designed for reading printed barcodes. It is good at reading high-density barcodes, dirty, defective, low contrast barcodes, etc. The scanning distance is long, the code scanning fluency is high, and it can be compatible with small barcodes at close range at the same time, and has good versatility.
S2-2: Designed for higher density or smaller DPM codes, and can adapt to more complex object surface environments, and can also recognize various types of DPMs with less than ideal recording quality. S2-2 loads the company's most powerful industrial decoding algorithm, with deep AI algorithm learning, to ensure that all kinds of DPM barcodes can be read smoothly.
Product Parameters
| Parameters | ||||
| Scanning performance | Resolution | 1280 Pixels(H) x 1024 Pixels(V) | ||
| Illumination | White light | |||
| Focus | S2-1 Green strip； S2-2 Red strip | |||
| Reading mode | Key scanning, Automatic induction scanning | |||
| Decode Capabilities | 1D |
UPC A , UPC E , EAN 8 , EAN 13 , Code 128 , Code 39 , Code 93 Code 32 , Code11 , Codabar ,Plessey , MSI , Interleaved 2 of 5 , IATA 2 of 5 , Matrix 2 of 5 , Straight 2 of 5 , Pharmacode , RSS-14 , RSS-14 Expanded , RSS-14 Limited Composite Code-A , Composite Code-B , Composite Code-C |
||
| 2D | Data Matrix , QR Code , Micro QR , PDF 417 , Micro PDF 417,Aztec, Maxicode | |||
| Reading accuracy | 1D : ≥3 mil ; 2D : ≥5 mil | |||
| Typical Depth of Field | Model | S2-1 | S2-2 | |
| Code 39 (3mil) | 55mm~150mm | 40mm~70mm | ||
| Code 39 (5mil) | 45mm~250mm | 30mm~100mm | ||
| Data Matrix (5mil) | 40mm~60mm | 40mm~70mm | ||
| 100%UPCA (13mil) | 40mm~500mm | 30mm~100mm | ||
| Field of view | Level 41° (H),Plumb 35° (V); | |||
| Print contrast | ≥20%(UPC/EAN 100% , PCS 90%) | |||
| Dimension | Physical dimension | 181x 102 x 77 mm | ||
| Electrical parameters | Weight | 150g (cable not included) | ||
| Communication interface | USB ,RS-232,Virtual COM Port | |||
| Data cable length | Straighten 2 meters | |||
| Prompt way | Buzzer,LED Indicator light, Vibration motor | |||
| Operating Voltage | DC 5V±5% | |||
| Working current | 300 mA ±5%(Typical value), 400 mA ±5%(Maximum value) | |||
| Stand-by current | 100 mA ±5% | |||
| Environmental parameters | Operating temperature | -20℃~+50℃ | ||
| Storage temperature | -40℃~+70℃ | |||
| Relative humidity | 5%~95%(no condensation) | |||
| Static Protection | ±12 kV(Air discharge),±8 kV (Direct discharge) | |||
| Drop height | 1.8m | |||
| Degree of protection | IP65 | |||
| Regulatory | FCC Part15 Class B,CE,EMC Class B | |||
