Data Collection PDA Barcode Scanner IP65 With Extraordinary Battery Life

Data Collection PDA Barcode Scanner IP65 With Extraordinary Battery Life

    • Data Collection PDA Barcode Scanner IP65 With Extraordinary Battery Life
    • Data Collection PDA Barcode Scanner IP65 With Extraordinary Battery Life
    • Data Collection PDA Barcode Scanner IP65 With Extraordinary Battery Life
    • Data Collection PDA Barcode Scanner IP65 With Extraordinary Battery Life
    • Data Collection PDA Barcode Scanner IP65 With Extraordinary Battery Life
  • Data Collection PDA Barcode Scanner IP65 With Extraordinary Battery Life

    Product Details:

    Place of Origin: China
    Brand Name: Rakinda
    Certification: CE CCC
    Model Number: S5 PLUS

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PC
    Price: negotiation
    Packaging Details: packing in carton
    Delivery Time: 1-3 work days
    Supply Ability: 200 pcs per week
    Contact Now
    Detailed Product Description
    Dimensions: 208mm(H)x130mm(W)x20mm(D)±2 Mm Operating System: Android 7.0
    Weight: 500g (including Battery&wrist Strap) SDK: HHW Software Development Kit
    1D Barcode: 1D Laser Engine 2D Barcode: 2D CMOS Imager
    Sealing: IP65, IEC Compliance Drop Specifications: 5ft./1.5 M Drop To Concrete Across The Operating Temperature Range

    S5 PLUS Android Mobile Computer
    S5 PLUS serial products extend Rakinda product serials into Android OS 7.0 with 4G high speed network communication. Compact tablet terminals, sealing level of IP65 water/dust proof, 1.5m/4.5ft drop survival, ergonomic design, over-molding structure, extremely large internal 10000mAh battery, quick- charging technology, and 7.0 inch tough Gorilla Glass 3 screen are all equipped to ensure performance. Latest 1.3GHz quad-core processor 2GB RAM/16GB ROM and up to 32GB expansion are all designed to boost up experience level.

    FEATURES:
    Extraordinary Battery Life
    Extremely large internal battery of 10000mAh can ensure long battery lin different using environment.
    Rugged Ergonomic and Over-molding Design
    Over-molding and ergonomic hardware design can satisfy most of the tough environment from different fields.
    Extremely Stable Hardware Display
    7.0 inch tough screen can ensure the performance under different tough environment.
    Highly Customized Structure
    ‘All-in-One’ hardware design conception can expand the hardware modules integration based on different project requirements, espcially like UHF+HF, UHF+LF, HF+LF.
    Highly Integrated and Preinstalled Application
    The highly integrated and preinstalled Scan Server can satisfy most of the solutions obtained from Google Play by the working principle of ‘Plug and Play’.
    Quick-Charging
    Quick-charging technology can provide the most efficient experience.
    Perfect Service
    Professional and skillful service involving the whole life cycle can guarantee the stability.
    Data Collection PDA Barcode Scanner IP65 With Extraordinary Battery Life

    SPECIFICATIONS
    PHYSICAL CHARACTERISTICS
    Dimension208mm(H)x130mm(W)x20mm(D)±2 mm
    WeightNet Weight :500g (including battery&wrist strap)
    DisplayGorilla Glass 3 9H 5.0 in. TFT-LCD(720x1280)touch screen with backlight
    BacklightLED backlight
    Keypads3 TP keys
    Expansions2 PSAM, 1 SIM, 1 TF
    BatteryRechargeable li-ion polymer, 3.7V, 10000mAh
    PERFORMANCE CHARACTERSTICS
    CPUQuad A53 1.3GHz quad-core
    Operating SystemAndroid 7.0
    Storage2GB RAM, 16GB ROM, MicroSD(max 32GB expansion)
    USER ENVIRONMENT
    Operating Temp.-20℃ to 50℃
    Storage Temp.-20℃ to 70℃
    Humidity5%RH to 95%RH(non-condensing)
    Drop Specifications5ft./1.5 m drop to concrete across the operating temperature range
    SealingIP65, IEC compliance
    ESD±15kv air discharge, ±8kv direct discharge
    DEVELOPMENT ENVIRONMENT
    SDKHHW Software Development Kit
    LanguageJava
    EnvironmentAndroid Studio or Eclipse
    DATA COMMUNICATION
    WWAN

    TDD-LTE Band 38, 39, 40, FDD-LTE Band 1, 2, 3, 4, 7;
    WCDMA(850/1900/2100MHz);
    GSM/GPRS/Edge 850/900/1800/1900MHz);

    WLAN2.4GHz/5.8GHz Dual Frequency, IEEE 802.11 a/b/g/n/ac
    WPANBluetooth Class v2.1+EDR, Bluetooth v3.0+HS, Bluetooth v4.0
    GPSGPS(embedded A-GPS), accuracy of 5 m
    DATA CAPTUER
    BARCODE READER(OPTIONAL)
    1D barcode1D laser engineHoneywell N431x
    SymbologiesAll major 1D barcodes
    2D barcode2D CMOS ImagerHoneywell N6603
    SymbologiesPDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. etc.
    COLOR CAMERA
    Resolution8.0 megapixel
    LensAuto-focus with LED flash
    RFID READER(OPTIONAL)
    RFID LFFrequency125KHz/134.2KHz(FDX-B/HDX)
    ProtocolISO 11784&11785
    R/W Range2cm to 10 cm
    RFID HFFrequency13.56MHz
    ProtocolISO 14443A&15693
    R/W Range2cm to 8cm
    RFID UHFFrequency865~868MHz or 920~925MHz
    ProtocolEPC C1 GEN2/ISO 18000-6C
    Antenna GainCircular antenna(2dBi)
    R/W Range1 m to 1.5 m(tags and environment dependant)
    Active 2.45GHzRead range more than 200 m
    433MHzRead range more than 200 m
    ZigBee READER(OPTIONAL)
    ProtocolIEEE 802.15.4
    Reading Range100 m to 200 m
    FINGERPRINT READER(OPTIONAL)
    SensorTCS1ST
    Sensor typeCapacitive, area sensor
    Resolution508 DPI
    PerformanceFRR<0.008%, FAR<0.005%
    Capacity1000
    PSAM SECURITY(OPTIONAL)
    ProtocolISO 7816
    Baudrate9600, 19200, 38400,43000, 56000, 57600, 115200
    Slot2 slots(maximum)
    ACCESSORIES
    Standard

    1xPower Supply
    1xLithium Polymer Battery
    1xDC charging cable
    1xUSB data cable

    OptionalMagnetic charging cable; Carrying case
